| NO. |
Name |
Qty. |
| 1 |
4P circuit breaker (DZ47sLE 16A with leakage protection) |
1 |
| 2 |
SB1 button box (red + green double button) |
1 |
| 3 |
SB2 button box (red + green double button) |
1 |
| 4 |
AC voltmeter (500V) |
1 |
| 5 |
AC ammeter (50A) |
1 |
| 6 |
DC voltmeter (500V) |
1 |
| 7 |
DC ammeter (50A) |
1 |
| 8 |
Tachometer (0-10V/0-1500r/min) |
1 |
| 9 |
Active wattmeter (1.2kW) |
1 |
| 10 |
Reactive wattmeter (1.2kvar) |
1 |
| 11 |
Fluorescent lamp (20W) |
1 |
| 12 |
3P circuit breaker |
1 |
| 13 |
Thermal relay (JRS2-63 1.6-2.5A) |
1 |
| 14 |
AC contactor (CJX2S-2510) |
2 |
| 15 |
Fuse |
3 |
| 16 |
Time relay (220V) |
2 |
| 17 |
Buzzer (AC220V) |
1 |
| 18 |
2P circuit breaker (DZ47S C6) |
1 |
| 19 |
Incandescent lamp (220V 40W) |
2 |
| 20 |
AC voltage regulator (0-250V) |
1 |
| 21 |
Isolation transformer (0-380V/0-220V) |
1 |
| 22 |
Resistor (1kΩ/150W) |
2 |
| 23 |
Capacitor (1μF) |
3 |
| 24 |
European socket |
1 |
| 25 |
Incandescent lamp switch |
2 |
| 26 |
Three-phase asynchronous motor (YS6344 0.37kW) |
1 |
| 27 |
DC shunt generator (DC220V 180W) |
1 |
| 28 |
Tachometer generator (0-10V output) |
1 |
